The following is a collection of problems commonly encountered in the daily use of the labeling machine and quick solutions.

Reasons and solutions when the labeling machine does not produce labels?

*The position of the measuring object electric eye is wrong, adjust the position of the measuring object electric eye

*The electric eye of the measuring object is faulty, and the electric eye of the measuring object is replaced.

* The labeling head label pull paper is not tight enough, adjust the pull paper

*The color of the object to be attached cannot be sensed by the electric eye, replace the electric eye with the appropriate type and function.

*The marker feeder is not turned on, the marker feeder is

*The power is not turned on, turn on the power

Causes and solutions of wrinkling after labeling by labeling machine?

*The speed of sending the standard is faster than the linear speed of the running surface of the material, so adjust the speed of marking down.

*Bid out too early, move the measuring object electric eye to the right

*The pre-out label is too long, reduce the pre-out label length

*The labeling speed is not fast enough, increase the labeling speed

Reasons and solutions for the labeling machine not sticking labels?

*Bid out speed is too slow, increase the bid out speed

*The position of the measuring object electric eye is wrong, adjust the position of the measuring object electric eye

*The pre-out label is not long enough, adjust the length of the reserved label

*The measuring object electric eye is too far from the outgoing end, move the measuring object electric eye to the right

*The material is not detected by the measuring object electric eye, adjust the measuring object electric eye

*The material interval is too small, increase the material interval

The labeling quality of the labeling machine is not good. What are the causes and solutions for bubbles or wrinkles?

1. If the labeling is not complete, the speed of labeling can be reduced.

2. It may be a transparent label, or the label is too soft.

3. Improper adjustment of the gravity of the overlay, it is important to adjust the force of the overlay.

4. There are wrinkles at the beginning of the labeling. It may be that the label is too soft, and the label has been bent when it is extended. The position of raising the peeling plate is as close to the product as possible.

5. If the front and rear of the label are not aligned, adjust the inclination of the support rod so that the product can be perpendicular to the extension direction of the label. Adjust the inclination of the support rod 2 through two screws 1 and 3 to correct the head-to-tail handover error of the label

6. The product moves in the other direction during the labeling process, slightly raising the support seat on the left side of the support rod.

The labeling machine has no response and no action, the reason and the solution?

1. Make sure the power cord is OK.

2. Confirm whether the fuse next to the input socket is in good condition. If it is burned out, please replace it.

3. The internal wiring of the electric box may be loose, please repair it by professionals.

Reasons and solutions for the inaccurate position of the labeling machine before and after labeling?

Adjust the front and back position of the measurement object or adjust the labeling delay.

Reasons and solutions for the labeling machine's header not sticking the label?

1. The bid-out speed is too slow, increase the bid-out speed

2. The reserved label is not long enough, adjust the length of the reserved label

3. The bidding speed is too fast, adjust the bidding speed down

4. The electric eye of the measuring object is too far from the marking end

5. The interval is too small, increase the speed of the pinch belt

6. The sticky label is poor or the object to be attached is not clean

Causes and solutions of wrinkling after the label of the labeling equipment is applied?

1. The reserved label is too long and the reserved length of the label is reduced

2. The speed of the label feeding is too fast and the speed of the entrainment belt is relatively slow, adjust the speed of the two to match
