Filling quantitative method for Filling machine

Filling quantitative method for Filling machine

1. Level control



This method is by controlling the height of the liquid level in the tank to be filled to achieve quantitative filling. Every time filling liquid volume equal to a certain height of the bottle cavity volume, it is also called "bottle quantitative." The method is very simple, does not require auxiliary equipment, easy to use. But for products requiring high quantitative accuracy should not be used, because the bottle volume accuracy directly affects the accuracy of filling volume.

2. Quantitative cup quantitative method



    In this method, the liquid is first poured into a measuring cup to be quantified, and then the metered liquid is poured into the bottle to be filled. Therefore, the volume of each filling is equal to the volume of the measuring cup.

3. Quantitative pump



    This is a quantitative method of pressure filling method, the power control piston reciprocating motion, the material is sucked into the piston cylinder from the storage cylinder, and then pressed into the filling container, each filling volume equal to the piston cylinder material Volume. In addition, there is also the use of a layer of soft film under the effect of gas pressure, the material is sucked into the filling chamber from the material cylinder, and then injected into the container.

4.Electronic measurement method



    Electronic metrology is a weight measurement, the filling valve has two different sizes of liquid passage through the liquid passage, the load cell real-time measurement of liquid weight, when the filling liquid close to the specified filling, the filling Valve can be converted into a small flow of the circuit, until filling to the required amount. This device before filling the display is cleared, the container weight measurement deviation, then reset, has no effect on the amount of filling, and thus filling accuracy is very high. When the filling volume changes, as long as the data switch to change a given value, you can instantaneous, easier to achieve centralized production management.

if you need the filling machine, please let me know.
